● 小型，大負載，可達16A
Small size, high load capacity of up to 16A
● 低功耗，可供200mW線圈功耗
Low power consumption, with a coil power consumption of 200mW.
Z5F | -12
| -1A | S | F | |||
基本型號 Type Z5F | |||||||
線圈額定電壓 Coil Voltage 05, 06, 09, 12, 24 | |||||||
線圈功耗 Nominal Power Blank=靈敏型 Sensitive Type (200mW) | |||||||
觸點結構 Contact of Arrangement 1A=Form1A | |||||||
封裝形式 Category of Protection Blank=非密封型 Flux proof, S=密封型 Wash Tight | |||||||
絕緣等級 Insulation Standard Blank=Class B; F=Class F; | |||||||
